Product Description

Pake Handling Tools DC powered 1300 lb load 63" height is a user friendly, portable hydraulic lift. Hand-held push button pendant control provides reliable, power lifting when moving and positioning loads. The non-slip chain is used for accurate positioning while the lift rolls easily on (2) floor-protective 4" polyurethane swivel casters with brakes and (2) 3-3/16" polyurethane load wheels. Stacker features adjustable 25-9/16"L x 4"W forks for added flexibility. Not for use with pallets.

Note: SPECIFIC USE: Use with Short Single Faced Pallets, Short Skids and Bulk Containers only.

About this item

1. Low profile forks lift skids easily.

2. DC 12V 800W High quality hydraulic motor.

3. (1) 12V 60Ah Service free battery

4. Max fork height: 63''; Min fork height: 3-17/32"

5. Fork length: 25-9/16"; Single Fork width: 4"; Fork Thickness: 7/25"; Adjustable fork width: 8"~21-21/32"

6. Weight: 363 lbs

Data Sheet

Length

41 in

Width

28-3/16 in

Height

75-3/16 in

Weight Capacity

1300 lb

Lowered Height

3-17/32 in

Raised Height

63 in

Fork Length

25-9/16 in

Fork Thickness

7/25 in

Single Fork Width

4 in

Adjustable Fork Width

8 to 21-21/32 in

Outrigger Distance (Inner)

15-21/32 in

Outrigger Length

24-1/4 in

Outrigger Width

3 in

Battery

DC-12V-60Ah

Hydraulic Power Pack

DC-12V-800W

Wheel Configuration

(2) Swivel With Brake, (2) Rigid

Wheel Material

Polyurethane

Steering Wheel

4 in

Loading Wheel

3-3/16 in

Assembly Required

Assembled

Net Weight

363 lb

Shipping Dimensions

48x40x81 in

Shipping Weight

410 lb
